Lithium Battery - LiFePo4 25,6V 120Ah/120A (3072Wh)

LiFePO4 25,6V 120Ah (120A) batteries with integrated BMS are characterized by very low weight and a large number of cycles (about 2000 cycles at an average of 100% of initial capacity). Thanks to high cyclicality and very low self-discharge, LiFePO4 battery is perfect for electric propulsion. Low weight allows the device to be used in installations in vehicles (campers, foodtrucks) and boats. Built-in BMS system ensures battery storage without loss of nominal capacity for a long time and controls the processes of charging and discharging the battery.

This battery can be connected in a maximum configuration of 4 series and 4 parallel connections.

Maximum battery bank: 102,4V 480Ah (49.15 kWh).

Technical specification:

Dimensions: 520mm x 269mm x 220mm

Weight: 35,6 kg

Cycles: 2000 (100% DOD)

Nominal voltage: 25,6V

Rated capacity: 120Ah

Max. cont. discharging current: 120A

Other data:

Terminal: M8

Cover material: ABS

Cells: 3.2V 120Ah 8S1P

Max. charge Voltage: 29,2V ±1.2V

Discharge cut off voltage: 18,8V

Max. charge current: 60A

BMS protection:

• Over charge
• Over discharge
• Over current
• Short circuit

Operating temperature:

• Discharging: -20°C to 60°C
• Charging: 0°C to 45°C
• Storage: 0°C to 45°C
